Central mix concrete plant is a type of concrete batch plant that not only combines the dry ingredients but also adds water to the concrete mixture. After mixed, the wet concrete mixture is then loaded into concrete mixer trucks and transported to the job sites.
Compared to ready mix concrete plant, central mix plants offer a lot more consistency, simply because all of the mixing is done on-site with extremely precise controls. Ready-mix concrete produced in ready mix concrete batching plant, on the other hand, its consistency can vary slightly from batch to batch due to the fact that the wet and dry ingredients for each batch are mixed separately inside of different concrete mixing truc
.
Our company, located in Zhengzhou, is a pioneer manufacturer of central mix concrete batching plant. With many years’ experience, our goal is to supply the best machine to customers. Central mix concrete batch plants adopt advanced technology, and now, they have been widely exported into worldwide countries. Besides, with the competitive price and high quality, the equipment is very popular both home and abroad. The following are types of our central mix concrete plants for sale.
| ype | HZS25 | HZS35 | HZS50 | HZS75 | |
| Theoretical production capacity(m3/h) | 25 | 35 | 50 | 75 | |
| Concrete mixer | Type | JS500 | JS750 | JS1000 | JS1500 |
| Power(KW) | 24.75 | 38.6 | 51 | 65.5 | |
| Discharging capacity(L) | 500 | 750 | 1000 | 1500 | |
| Aggregate size(Pebble/Macadam)(mm) | 80/60 | 80/60 | 80/60 | 80/60 | |
| Aggregate Bin volume(m3) | 2/3×3.2 | 2/3/4×7.3 | 2/3/4×8.3 | 2/3/4×12 | |
| Weighing Accuracy | Aggregate (KG) | 1500Kg ±2% | 2200Kg ±2% | 3000Kg ±2% | 4500Kg ±2% |
| Cement(KG) | 300Kg ±1% | 450Kg ±1% | 600Kg ±1% | 1500Kg ±1% | |
| Fly ash(KG) | 400Kg ±1% | 600Kg ±1% | |||
| Water (KG) | 200Kg ±1% | 200Kg ±1% | 400Kg ±1% | 600Kg ±1% | |
| Additive(KG) | 30Kg ±1% | 50Kg ±1% | 50Kg ±1% | ||
| Discharging height(M) | 3.8 m | 3.8 m | 3.8 m | 4.1m | |
| Gross weight(T) | 10 | 15 | 40 | 50 | |
Usage of central mixing plant:
Central concrete batching plants adopt JS twin-shaft mixer, so it can mix dry-hard concrete, plastic concrete, lightweight aggregate and kinds of mortar. What’s more, due to its high working efficiency and large capacity output, the central mixing plant is widely used in large and medium sized construction, road, bridge, railway and others. In short, the central concrete batch plant is ideal equipment for users to buy.
Features of central concrete mix plants:
1. The mixing system adopts JS series twin-shaft concrete mixer with good mixing homogeneity.
2. With compact structure of modular organization, which can meet the requirements of container transport, and is convenient for transport and quick installation dis-assembly.
3. Aggregate lifting appliance adopts frequency control, thus providing smooth and reliable operation.
4. Lubrication system adopts advanced centralized oil lubricating system, convenient for oil supplying, this system is equipped with over voltage warning and low oil level warning, safe and reliable.
Specifications of central concrete mix plant:
| Type | HZS60 | HZS90 | HZS120 | HZS180 | HZS240 | |
| Theoretical production(m3/h) | 60 | 90 | 120 | 180 | 240 | |
| Concrete mixer | Type | JS1000 | JS1500 | MAO3000/2000 | MAO4500/3000 | MAO6000/4000 |
| Power(KW) | 18.5 | 65.5 | 74 | 110 | 150 | |
| Discharging capacity (L) |
1000 | 1500 | 2000 | 3000 | 4000 | |
| Aggregate size (Pebble/ Macadam) (mm) |
80/60 | 80/60 | 80 | 150 | 150 | |
| Aggregate Bin volume(m3) | 8.38 | 12 | 20 | 30 | 40 | |
| Belt conveying Capacity(t/h) | 300 | 450 | 550 | 650 | 900 | |
| Weighing Accuracy | Aggregate (KG) | 3000Kg ±2% | 3000Kg ±2% | 2200Kg ±2% | 3000Kg ±2% | 4200Kg ±2% |
| Cement(KG) | 1500Kg ±1% | 1500Kg ±1% | 1200Kg ±1% | 1800Kg ±1% | 2200Kg ±1% | |
| Fly ash(KG) | 600Kg ±1% | 900Kg ±1% | 400Kg ±1% | 500Kg ±1% | 800Kg ±1% | |
| Water (KG) | 600Kg ±1% | 600Kg ±1% | 500Kg ±1% | 800Kg ±1% | 1000Kg ±1% | |
| Additive(KG) | 50Kg ±1% | 50Kg ±1% | 50Kg ±1% | 80Kg ±1% | 80Kg ±1% | |
| Total power(KW) | 120Kw | 165Kw | 130Kw | 170KW | 220KW | |
| Discharging height(M) | 3.8 m | 4.1 m | 4.1m | 4.1m | 4.1m | |
